Filters and Pressure Regulators

TECO Pressure Reducers

Easy to install Y Filters with Pressure Reducers and Inline Pressure Reducers

To ensure that your irrigation system is working at its optimal conditions in terms of water pressure and water quality.

Main models have 3/4 in. Threaded connections.

Also available models with Barbed connection.

Models with distinct pre-defined outlet pressure regulation.

Key Benefits

  • Easy to install
  • Colour coded, for faster selection (colour indicates the pre-defined pressure)
  • 4 pre-defined outlet pressures: 1,0 bar, 1,4 bar, 1,8 bar and 2,5 bar
  • Y Filters with Pressure Reducers available in Male x Male and Female x Male Threaded options, each with 4 pre-defined outlet pressures
  • All the filters have a 150 mesh stainless steel filter screen that traps particles in the water, to reduce clogging of emitters
  • The 3/4" Female Thread Nut on the Y-Filters and the Inline Pressure reducers rotates independently from the body

Applications

Landscape gardens, greenhouses and vegetable gardens.

Materials & Sustainability

  • Body: Nylon
  • Caps: Nylon
  • Swivel Nuts: Nylon
  • Washers: Rubber
  • Internals: Acetal
  • O-Rings: EPDM
  • Filters: Stainless Steel Mesh
  • Body (in-line filters): Polypropylene

Models

  • Y Filters with Pressure Reducers available in Male x Male and Female X Male Threaded options, each with the 4 pre-defined outlet pressure regulations
  • Inline Pressure Reducers with Female x Male connections and the same 4 pre-defined outlet pressures
  • Also available one piece Y Filter, with no pressure regulation, with Male x Male and Female x Male connections.
  • Filter Inline Barbed options include 13mm, 14mm, 16mm and 20mm Barbed x Barbed. The same sizes also available in 3/4 in. Female Thread x Barb.
  • Inline Filter also available in 3/4 in. Female x Male.
