Runoff from Neighbor's Property (Low): Installation Instructions
DOWNLOAD AS PDF

Prior to installation, have your local utility companies locate and mark the location of existing utilities.

Layout your drainage system and mark the location of trenches and individual parts to be installed with marking paint before digging. Carefully remove grass or plants that are located where the trench will be dug so they can be replanted after installation. Trenches should be dug such that they slope a minimum of 1% away from your house. Place all excavated dirt on a tarp so that it can be used later to backfill.

To speed up installation, a trenching machine can be used to dig all trenches, especially in areas with particularly hard soil. NDS drainage products have been designed to be installed in any soil type. Due to the variety of pipe types and sizes, double check that all pipe connection points are the correct size. Please follow all installation directions included with the individual parts of your drainage system. To create watertight connections between products, apply a bead of waterproof silicone to both parts and connect.

This system requires that the elevation of the Pop-Up Emitter be lower than the elevation of the area drain or the system will not drain.

  • Dig trench for the drain pipe and Spee-D basins along the property line where the runoff is draining onto your property.
  • The Spee-D Basin should be installed under the areas where the runoff is collecting.
  • Dry fit (no glue) the entire drainage system from the Spee-D Basin to the pop-up emitter.
  • Measure and cut all pipe to necessary lengths. After completing each step, glue parts together.

  • If using multiple Spee-D basins, connect the basins with a section of drain pipe.
  • Use additional sections of pipe to connect the Spee-D Basin to the Pop-up emitter and elbow.

TIP: Dig the hole for the basin an additional 6 in. deeper than needed. Place 6 in. of gravel in the bottom of the hole. Drill small holes in the bottom of the basin to prevent standing water in the bottom of the basin.

Install Spee-D Basins

  • The elbow should be installed with the weep hole on the horizontal side of the elbow.
  • Slide the Pop-up Emitter onto the elbow. An additional length of pipe can be used between the elbow and Pop-Up Emitter to bring the Pop-up emitter to the surface.
  • The Pop-Up Emitter fits on the bell or hub end of the pipe or a pipe coupler.


TIP: To avoid damaging your Pop-Up Emitter with your lawn mower, raise the cutting level of the blades or avoid passing the mower over the Pop-Up Emitter.

Install pop-up emitter on pipe

  • Backfill and replace any grass or plants that were removed.
