BG-FILCOTEN® 300 Trench Drain Grate, 13.66 in. Wide X 19.69 in. Long, Decorative Ville Slot Design, NDS Class E Load, Ductile Iron

SKU:

17030180

Add a distinguished look to the drainage system with the elegant Ville drain grate. This decorative grate has an intricate design that blocks leaves and debris while water flows through. Rated for NDS Class E loads when properly installed. The ductile iron drain cover has an open surface area of 82.2 sq. in. per meter and flow rate of 251.8 GPM per meter. Grate is ADA compliant and heel proof. Two half-meter (19.69 in.) grates will cover one BG-FILCOTEN 300 12 in. trench drain. Iron grates are painted black to inhibit rust. Over time, it will form a protective iron-oxide patina.

Where to Buy Find a Contractor

Applications

Prevents leaves and debris from entering the drainage system
Ideal for factories, warehouses, garages, railway stations, municipal areas, and areas with similar surfaces
As part of a complete drainage system, the BG-FILCOTEN® trench drain grate works with the channel drain to capture stormwater runoff and convey it to drain pipe for proper release downstream

Features

Grate is 13.66 in. wide and 19.69 in. long, works with BG-FILCOTEN pro V 300 channels
Rated for NDS Class E loads, handles up to 134,800 lbs.
Grate is secured to channel body with four-point snap-in locking system

Literature & Resources

NDS Drainage Product Catalog 2024-2025

Catalogue

NDS Drainage Product Catalog 2024-2025

Guía de diseño y instalación de drenaje

Reference (NDS)

Guía de diseño y instalación de drenaje

NDS BG-FILCOTEN® Trench Drains & Grates Written Spec

CSI Specifications

NDS BG-FILCOTEN® Trench Drains & Grates Written Spec
