5 in. Pro Series™ Channel Drain 45° Elbow and Grate, Deep Profile, Lt. Gray Plastic

SKU:

862
NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow, in light gray plastic (NDS 862)
Top down view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)
Female end view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)
Male end view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)
NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow, in light gray plastic (NDS 862)
Top down view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)
Female end view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)
Male end view of the NDS 5 in. Pro Series Deep Profile Channel Drain and Grate with 45° Elbow (NDS 862)

Customize your Deep Profile 5 in. Pro Series™ Channel Drain system with 45° turns in your layout. No need to saw a straight channel drain and grate to miter an angled turn—the 5 in. Pro Series Channel Drain 45° Elbow and Grate is ready to connect to your system with built-in interlocking joints. Channel is made of polypropylene and grate is made of light gray polyethylene treated with UV inhibitors. Works with the 5 in. Pro Series Deep Profile Channel Drain system to drain moderate flows on driveways, concrete & paver patios, courtyards, walkways, & sports facilities.

Where to Buy Find a Contractor
Applications
  • Add a 45° turn left or right in your 5 in. Pro Series Channel drainage system layout
  • The 5 in. Pro Series Channel Drain system collects moderate flows from driveways, concrete & paver patios, courtyards, walkways, and sports facilities, and directs the water to drain pipes for proper release downstream
  • Works with 5 in. Pro Series Deep Profile Channel Drain system
Features
  • Channel drain with 45° elbow and drain grate makes it easy to customize channel layout
  • Built-in interlocking joints make it easy to connect to the system
  • N/A
