By NORMA Group

Dura Slope® Channel Drain Grate, 6 in. Wide X 2 ft. Long, Ductile Iron

SKU:

DS-232

Alternate view of the NDS Dura Slope Ductile Iron Channel Grate (NDS DS-232) showing female end of drain (NDS DS-091)

Angled Closeup view of the grate design on the NDS Dura Slope Ductile Iron Channel Gratee (NDS-232)

Close up on the female end of the NDS Dura Slope Ductile Iron Channel Grate (NDS DS-232) and drain (NDS DS-091)

Keep leaves and debris out of your drainage system with the Dura Slope® Channel Drain Grate. Works with the Dura Slope Channel Drain to capture sheet flows from impervious surfaces. Also known as a drain cover, the ductile iron grates are painted black to inhibit rust and over time form a protective iron-oxide patina. Grate has an open surface area of 20.85 sq. in. per linear ft. and flow rate of 63.78 GPM per linear ft. Rated for NDS Class C Loads (up to 325 PSI) when properly installed; rated for NDS Class D loads (up to 575 PSI) and H-20 rated when properly installed with the Ductile Iron Frame (DS-200H); ADA compliant.

Where to Buy Find a Contractor

Applications

Prevent leaves and debris from entering the channel drain and clogging the drainage system
Use with the Dura Slope Channel Drain to collect water flows from driveways, parking areas, warehouses, loading docks, pools, wash-down areas, and other impervious surfaces
As part of a complete drainage system, the Dura Slope channel drain and drain grate work together to capture stormwater runoff and convey it to drain pipe for proper release downstream

Features

Grate is 24 in. long, 6 in. wide and 3/4 in. high
Grate openings are 1/4 in
Dura Slope Channel Drain Grates are available in a variety of materials, colors, and designs
