Hydroport™ Adjustable Flow Bubbler, Four Outlets from 0 to 20 GPH, 1/2 in. FPT Inlet, 10-Pack

SKU:

HPAM 4

Side View of the Hydro-Port® Adjustable Four Outlet Bubbler, up to 20 GPH per Outlet. (NDS HPAM 4)

Bottom View of adjustable 4 ports on Hydro-Port® Adjustable Four Outlet Bubbler and sprinkler connection (NDS HPAM 4)

The Hydro-Port® Adjustable Four Outlet Bubbler installs on a sprinkler head to convert to a drip system with adjustable dials on top (NDS HPAM 4)

Deliver precise watering for up to 4 individual plants with the Hydroport™ Adjustable Flow Bubbler. The non-pressure compensating emitter has a 1/2 in. FPT inlet which screws onto an underground sprinkler riser. Bubbler comes equipped with 4 barbed swivel outlets that connect to 1/4 in. distribution tubing (A220 and A250) or 1/4 in. DuraFlo™ JR dripline; rotating outlets allow tubing to be positioned as desired. The discharge rate of each adjustable outlet can be individually set from 0 to 20 GPH. The Hydroport Bubbler features a built-in removable filter to help prevent clogging. Filter can be cleaned to extend the system lifespan. Made of ABS plastic treated with UV inhibitors to prevent fading and cracking.

Where to Buy Find a Contractor

Applications

Converts an underground sprinkler system to a micro irrigation drip system that waters up to 4 plants with variable flow rates per outlet
Ideal for landscaped perimeters and garden areas; can be used above grade or below grade in an emitter access box
As part of a complete drip system, the bubbler delivers low volume irrigation to the plant’s root zone; with a non-pressure compensating emitter, the longer the run the lower the volume of output as water travels further away from the water source

Features

Converts a sprinkler riser into a multi-outlet, low-flow drip irrigation emitter
Four barbed swivel outlets enable tubing to be positioned where desired
Each outlet has an individually adjustable discharge rate from 0 to 20 GPH; turn dial with coin or flathead screwdriver to adjust rate
