6 in. Square Grate with Low-Profile Adapter Drain, Connects to 3 in. and 4 in. Drain Pipes and Fittings, Satin Brass and Plastic

SKU:

920B

NDS Satin Brass and plastic 6 in. Square Grate fits 3 & 4 in. Drain Pipes & Fittings installed in 4 in. S&D Pipe (NDS 920B)

NDS Satin Brass and plastic 6 in. Square Grate fits 3 & 4 in. Drain Pipes & Fittings installed in 4 in. Sing-Wall Corrugagted Pipe (NDS 920B)

NDS Satin Brass and plastic 6 in. Square Grate fits 3 & 4 in. Drain Pipes & Fittings installed in 4 in. S&D Elbow (NDS 920B)

Top Down View of the NDS 6 in. Square Grate (NDS 920B)

Side view to see the thickness of the NDS 6 in. Square Grate (NDS 920B)

Upside down view of the NDS 6 in. Square Grate to see the circular opening (NDS 920B)

Closeup of the NDS 6 in. Square Grate (NDS 920B)

To keep your drainage system running smoothly, prevent the debris in stormwater from entering and potentially clogging your drain pipes. The 6 in. Square Brass Grate with Low-Profile Adapter Drain has an open surface area of 11.6 sq. in. and flow rate of 35 GPM; drains light flows from small lawns, landscaped areas, patios, and walkways. The 6 in. Square Drain Grate with Low-Profile Adapter Drain fits right onto 3 in. & 4 in. sewer and drain pipes & fittings, single-wall corrugated pipe, and triple-wall pipe. The rust- and corrosion-resistant brass grate is fitted onto a high-impact polystyrene (HIPS) low-profile adapter treated with UV inhibitors. Hassle-free limited lifetime warranty guarantees the NDS product is free from defects—or we’ll replace it.

Where to Buy Find a Contractor

Applications

Protect your drainage system by using a grate on top of drain pipe to block debris from entering and potentially clogging the pipeline while letting excess surface water flow through
Ideal for draining light water flows from small lawns, landscaped areas, patios, and walkways
Works with connected drain pipe to capture and convey excess surface water for proper release downstream

Features

Grate with low-profile adapter is 2-3/4 in. high; top is 6-1/8 in. square; grate openings are 3/8 in. wide
6 in. Square Drain Grates (with Low-Profile Adapters) are available in a variety of colors and materials
