By NORMA Group

PVC Compact True Union Spring Check Valve, 2 in. IPS S X S, 1/2 lb. Spring, White

SKU:

1790-20

Side view of the NDS 2 in. IPS slip by slip PVC Compact True Union Spring Check Valve (NDS 1790-20)

The flapper controls the flow of water on the NDS 2 in. IPS slip by slip PVC Compact True Union Spring Check Valve (NDS 1790-20)

Inside view from outlet end of the NDS 2 in. IPS slip by slip PVC Compact True Union Spring Check Valve (NDS 1790-20)

Closeup of one connection end of the NDS 2 in. IPS slip by slip PVC Compact True Union Spring Check Valve (NDS 1790-20)

Closeup of the directional arrow on the NDS 2 in. IPS slip by slip PVC Compact True Union Spring Check Valve (NDS 1790-20)

The PVC Compact True Union Spring Check Valve, 2 in. IPS S X S is compact to make installation easier for applications with limited space in their pipelines. Allow water to flow one-way through pipe and prevent backflow with this check valve. The 1/2 lb. spring lifts when the water pressure exceeds the spring weight to let water through and closes to prevent water from going the wrong way through the irrigation system. This easy-fit check valve connects two 2 in. slip end pipes as a part of a complete irrigation or other pressurized system. Prevents costly property damage, pipe corrosion, and system issues. Durable check valve is made of PVC plastic. Pressurized Spring is made of stainless steel. Washer and O-Ring are made of EPDM. Use fittings and other valves to set up a new irrigation system, expand an existing system, or make repairs.

Where to Buy Find a Contractor

Applications

Allows water to flow one-way through pipe when the water pressure is greater that the weight of the spring valve. Able to unscrew both ends of valve. Prevents costly property damage, pipe corrosion, and system issues
Used for irrigation in plumbing, pools and spas; works with pipe to transport water and prevent backflow
As part of a complete flow management system, the Compact True Union Spring Check Valve works with PVC pipes and other compatible system components to allow water to flow through

Features

Valve is removable; ends unscrew to remove valve from line
Valve is compact; less bulk makes installation easier for applications with limited space
1/2 lb. spring allows water through when water pressure exceeds its force
