13 in. X 20 in. Rectangular Standard Series Jumbo Valve Box and Cover, 12 in. Height, Black Box, Green ICV Cover

SKU:

117BC

Alternate View of the top of 13 in. X 20 in. Rectangular Jumbo Green ICV Cover with bolt hole to secure lid (NDS 117BC)

Alternate View of the bottom of 13 in. X 20 in. Rectangular Jumbo Green ICV Cover with reinforcing ribs (NDS 117BC)

View of the Black 13 in. X 20 in. Rectangular Jumbo Valve Box which conceals and protects components (NDS 117BC)

Closeup View of the Rectangular Jumbo Valve Box PVC pipe hole; allows irrigation pipe entry into box interior (NDS 117BC)

Guard underground irrigation and sprinkler system components against damage with the 13 X 20 in. Rectangular Standard Series Jumbo Valve Box and Cover. Designed for durability, the black access box is engineered with structural reinforcing ribs. Built-in pipe holes allow irrigation piping to pass through the walls of the box so that the box does not rest on the pipe. The durable enclosure features the patented Universal Locking Mechanism (ULM) that enables the valve box cover to be secured with a variety of bolts and screws (3/8 to 1/2 in. diameter, minimum 2-1/2 in. length) and without the need for a nut. Box includes a speed nut shelf as an alternative way to secure the cover (bolt and nut not included). Box stands 12 in. high and comes with an overlapping cover to keep debris from entering the box. Molded into the cover are the markings "IRRIGATION CONTROL VALVE" to identify components. The green lid also indicates where to lift. The box is made of polypropylene (PP) and the lid is made of high-density polyethylene (HDPE), both treated with UV inhibitors.

Where to Buy Find a Contractor

Applications

Protects critical infrastructure such as irrigation control valves, sewer cleanouts, wire splices, and backflow valves, and keeps them out of sight
Fits over underground components
Protects components from the elements, foot traffic, lawncare equipment, and potential vandalism

Features

Patented Universal Locking Mechanism (ULM) enables the valve box lid to be secured without requiring a traditional nut; works with a variety of bolts and screws from 3/8 in. to 1/2 in. in diameter and at least 2-1/2 in. long
Conceal and protect components without cluttering the landscape
Built to last with structural reinforcing ribs for durability; box made of polyethylene (PP) and cover made with high-density polyethylene (HDPE), both treated with UV inhibitors
