By NORMA Group

6 in. Round Spee-D® Catch Basin Drain, 1 Outlet

SKU:

101

NDS 6 in. Round Spee-D Catch Basin Drain with 1 outlet (NDS 101)

The bottom of the 6 in. Round Spee-D® Catch Basin Drain (NDS 101) includes two punch out weep holes

Angled top down view of inside the NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101)

Connect multiple 6 in. Round Spee-D® Catch Basin Drains, including 1 outlet (NDS 101) and 2 outlets (NDS 201), together with pipe

The outlet on the NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101) connects to 4 in. Sewer and Drain pipe.

The outlet on the NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101) connects to 4 in. corrugated pipe.

The outlet on the NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101) connects to 3 in. Sewer and Drain pipe.

The outlet on the NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101) connects to 3 in. corrugated pipe.

The NDS 6 in. Round Spee-D® Catch Basin Drain (NDS 101) works with the NDS Pop-Up Drainage Emitter (NDS 420)

Inside view of the 6 in. Round Spee-D® Catch Basin Drain (NDS 101) with knockout weep holes in the bottom

Closeup view of the bottom of the 6 in. Round Spee-D® Catch Basin Drain (NDS 101) with knockout weep holes

Closeup view of how the 6 in. Round Spee-D® Catch Basin Drain (NDS 101) stacks on top of each other

When rainfall leaves a flooded, mucky mess on your lawn, it can also erode the soil and seep into your home’s foundation. The Spee-D® Catch Basin helps prevent costly property damage by providing an effective way to drain. The Spee-D® Catch Basin drain works with a drain grate (sold separately) to collect water from flood-prone areas such as lawns, landscaped areas, patios, and walkways, and direct the water to drain pipe. Use the 1-outlet stormwater catch basin alone or to start a series of connected basins positioned downstream. Basin outlet with locking flex tabs connects to 3 in. & 4 in. single-wall corrugated, sewer and drain, and triple-wall pipes, and 4 in. Sch. 40 pipe. Made of high-impact polystyrene (HIPS) treated with UV inhibitors. Basin sump area collects debris and is easily accessible to clean.

Where to Buy Find a Contractor

Applications

Collect stormwater runoff and standing water on your property and direct to drain pipes before it causes costly property damage
Ideal for capturing excess water from lawns, downspouts, and landscaping
As part of a complete drainage system, the catch basin with grate captures surface water and directs it to connected drain pipes for proper release downstream

Features

Use the one-outlet catch basin alone or to start a series of connected basins positioned downstream
Outlet features locking flex tabs for a secure connection to pipe—no tape or glue required
Available in single and multiple outlets
