5 in. Pro Series™ Channel Drain Kit, 5-1/2 in. X 39-3/8 in. Deep Profile Channel, Gray Plastic Grates, End Caps/Outlet

SKU:

864
Applications
  • Channel drains and trench drains capture and convey excess water to prevent mildew growth, concrete staining, and costly structural damage
  • 5 in. Pro Series Channel Drain system collects moderate water flows from driveways, concrete & paver patios, courtyards, walkways, and sports facilities, and directs it to drain pipes for proper release downstream
  • Works with 5 in. Pro Series Channel Drain components
Features
  • The 5 in. Pro Series Channel Deep Profile Drain is 4-3/4 in. deep and features a modular design with interlocking joints for a secure channel-to-channel connection—no couplings required; easy to cut to size in 4 in. increments with saw guide
  • Included end cap/outlet combined with integrated bottom outlet and side outlet knockouts provide 8 outlet options per channel section
  • Channel-to-channel clips reduce motion during installation; rebar clips instead of lower mount clips make installation easier

Literature & Resources

Videos
