By NORMA Group

Spee-D® Channel Drain with Bottom Outlet, 4-3/4 in. X 2 ft., Connects to 3 in. and 4 in. Drain Fittings

SKU:

234

Hero shot of NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234, NDS 234*) which collects and conveys stormwater away for proper release downstream

Bottom view of the NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234) which collects and conveys stormwater away for proper release downstream

Connect 3 inch or 4 inch sewer and drain fittings to the NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234) shown here with a NDS 3 inch PVC S&D 90° Elbow (NDS 3P02)

Connect 3 inch or 4 inch sewer and drain fittings to the NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234) shown here with a NDS 4 inch PVC S&D 90° Elbow (NDS 4P02)

Inside view of the bottom outlet grate connected to the NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234) which collects and conveys stormwater away for proper release downstream

Closeup shot of the bottom pipe connection point on the NDS Spee-D® Channel Drain with Bottom Outlet (NDS 234) which collects and conveys stormwater away for proper release downstream

Take stormwater from channel drain to drain pipe along the length of your channel run with the Spee-D® Channel Drain with Bottom Outlet. The 2 ft. long channel drain features an integrated bottom outlet with built-in strainer; outlet connects to 3 in. & 4 in. sewer and drain fittings. Channel fits one 2 ft. Spee-D Channel Drain Grate on top. The Spee-D Channel Drain with Bottom Outlet is made of polyvinyl chloride (PVC) treated with UV inhibitors. Spee-D Channels are part of the NDS Profile Channel series, and ideal for capturing light to moderate flows from driveways, concrete & paver patios, pool areas, courtyards, and walkways.

Where to Buy Find a Contractor

Applications

Use the Spee-D Channel Drain with Bottom Outlet anywhere along the channel run to outlet water to drain pipe; channel drains and trench drains capture and convey excess water to prevent mildew growth, concrete staining, and costly structural damage
Spee-D Channel Drain system collects light to moderate water flows from driveways, concrete & paver patios, pool areas, courtyards, and walkways, and directs it to drain pipes for proper release downstream
Works with Spee-D Channel Drain system; part of the NDS Profile Channel series

Features

Spee-D Channel Drain with Bottom Outlet is 4-3/4 in. wide and 2 ft. long; length can be cut to size with a saw
Patented flying buttress design provides load-bearing support from both sides as well as underneath the channel
Bottom flanges provide an anchoring lip for straight installation and prevents floating
